Description
10000W High Power SCR BTA100-800B Electronic Voltage Regulator Module is your solution to efficient power management. This module is designed for controlling the voltage supply to various electrical devices, including speed regulation of motors, dimming of lamps, and controlling thermostats. It allows you to maintain the optimal performance of your devices by adjusting the voltage supply as needed. Featuring stable performance with enhanced heat dissipation, the regulator is ideal for both AC and DC voltage applications such as buck converter and buck controller setups.
Key Features - Voltage Regulator
- Voltage: AC 220V with adjustable regulation from 0V to 220V, ensuring flexibility in application.
- Capable of handling high power output of up to 10,000W, with a constant 5,000W usage at room temperature for long durations.
- Double circuit board design ensures enhanced stability and reliability.
- Integrated High-voltage condenser for durable performance.
- ST trigger diode incorporated for precise voltage control.
- Utilizes a BTA100-800B SCR component for efficient and reliable performance.
- Includes a cooling fan to prevent overheating during high-load operations.
Applications
This voltage regulator is perfect for speed control of electric motors in industrial environments, which require voltage regulator transformers, dimming of lights in theaters, and monitoring of heating devices within HVAC systems where dc voltage regulators are beneficial. Its adaptability makes it essential for household appliances and industrial machinery.
Technical Specifications
Product Specification | Value |
Model Type | Regulator Module |
Voltage Regulation (U) | AC 0V to 220V |
Maximum Power | 10,000W |
Continuous Power Usage | 5,000W |
Controlled SCR | BTA100-800B |
Dimensions (LxWxH) mm | 150x60x47 |
Weight (g) | 230 |
How to Use - Voltage Regulator
- Connect the input terminals of the module to the AC power supply.
- Connect the output terminals to the device you wish to control (e.g., motor, lamp).
- Adjust the potentiometer or control knob to set the desired voltage level, monitored via an external multimeter for precision.
- Monitor and adjust as necessary to achieve optimal performance in your device. If operating at higher power outputs, installation of an additional fan is recommended for effective cooling.
- Ensure all power sources are disconnected before wiring to prevent electric shock and follow safety protocols to avoid direct contact with internal wiring during operation.
Package Includes
1 x 10000W High Power SCR BTA100-800B Voltage Regulator Module
Additional Resources
Download DatasheetLearn more about Voltage Regulator
Explore our electronic-modules-and-displays Collection
Video Tutorials
Specification
Product Specification | Value |
Model Type | Regulator Module |
Voltage regulation (U) | AC 10V to 220V |
Dimensions (L x W x H) mm | 150X60X47 |
Weight (g) | 230 |
Shipping Weight | 0.25 kg |
Shipping Dimensions | 16 × 7 × 5 cm |
