5V 4 Channel SSR Solid State Relay Module is based on the Omron G3MB SSR relay, efficiently managing up to 2A at 240VAC. This solid state relay module is designed for switching high voltage loads with minimal noise and quick response time, providing versatility in connections with NO, COM, and NC terminals per relay. Its noise-free operation, combined with extended durability, makes it perfect for applications like ssr relay 3 phase, solid state relay module, and ssr relay module.
Key Features - 5V 4 Channel SSR Solid State Relay Module
- Based on Omron G3MB SSR relay
- Solid-state relay ensures high-speed switching without mechanical wear and tear
- Controls up to 2A at 240VAC
- 4 channels with NO, COM, and NC terminals
- Opto-isolation for high voltage protection of the control circuit
- Built-in resistive fuse for enhanced safety
- Low control signal voltages (3-5V) required for operation
- LED indicators for each relay
- No noise operation and extended lifespan
Applications
The module is perfect for g3mb 202p and 5v solid state relay applications. This SSR module seamlessly integrates into industrial control systems and home automation, allowing control of appliances like lights and fans. It is extensively used in projects such as arduino ssr relay and solid state relay arduino, linking with microcontroller platforms for reliable switching.
Technical Specifications
| Product Specification | Value |
| Model Type | Relay Module |
| Relay Type | Solid State Relay (SSR) |
| Number of Channels | 4 |
| Trigger Current (mA) | 2 |
| Trigger Voltage (VDC) | 5 |
| Switching Voltage (VAC) | 240@2A |
| Operating Voltage | 5V DC |
| Maximum Load Current | 2A per channel |
| Control Signal Voltage | 3-5V |
| Isolation | Opto-isolated |
| Additional Protection | Resistive fuse per channel |
| LED Indicators | Yes, for status indication |
| Module Size | Typically compact to fit on standard breadboards or project enclosures |
How to Use - 5V 4 Channel SSR Solid State Relay Module
- Connect DC+ and DC- to the power source's positive and negative terminals, respectively.
- Use a digital signal to trigger CH1 through CH4 for each relay, ensuring it's a low-level trigger.
- Connect the module to a 5V DC power supply for operation.
- Integrate the control pins to your microcontroller or control system operating within a 3-5V range.
- Connect the AC load to the respective output terminals of each SSR channel.
- Monitor the onboard LED indicators for switching status verification.
- Ensure the load connected does not exceed the rated current and voltage to prevent damage.
Package Includes
1 x 5V 4 Channel SSR Solid State Relay Module
Additional Resources
Learn more about Solid State Relay ModuleExplore our electronic-modules-and-displays Collection
Video Tutorials
Specification
| Product Specification | Value |
| Model Type | Relay Module |
| Number of Channels | 4 |
| Trigger Current (mA) | 2 |
| Trigger Voltage (VDC) | 5 |
| Switching Voltage (VAC) | 240@2A |
| Length (mm) | 57 |
| Width (mm) | 55 |
| Height (mm) | 25 |
| Weight (g) | 38 |
| Shipping Weight (kg) | 0.039 |
| Shipping Dimensions | 8 × 8 × 4 cm |
