Description
A2212 1000KV BLDC Brushless DC Motor is the perfect choice for drone enthusiasts who seek performance without breaking the bank. Known for its great price-performance ratio, this brushless dc motor is ideal for those stepping into the world of DIY drones. Despite its affordability, this brushless direct current motor ensures a thrust of around 700gm, surpassing many competitors in the market. Designed for use in multi-rotor aircraft and remote-controlled applications, it offers optimal performance and reliability, making it popular among hobbyists and enthusiasts.
Key Features - A2212 1000KV BLDC Brushless DC Motor
- High-performance motor suited for drones
- Cost-effective option for enthusiasts
- Offers thrust of around 700gm
- Easy compatibility with 2S to 3S LiPO batteries
- Equipped with On-Board BEC for enhanced control
- Solid metal casing ensures durability
- High efficiency with a low current draw
- Smooth operation with powerful torque
- Designed for long-lasting performance
- Compatible with a variety of multi-rotor and remote-controlled aircraft
- Comes with a SimonK 30A ESC for improved control and responsiveness
Applications
Ideal for use in quadcopters, hexacopters, and RC planes, the 1000kv drone motor, when combined with the brushless motor and brushless dc electric motor, delivers efficient and reliable performance. This motor and ESC combo is frequently utilized in DIY drone kits, Q450 quadcopter frames, and other RC applications that require robust thrust and reliability.
Technical Specifications
| Product Specification | Value |
| Motor KV | 1000 (RPM/V) |
| Motor Type | Brushless DC Outrunner |
| LiPO Batteries | 2S-3S |
| Max Efficiency Current | 4 ~ 10A |
| Max Power | 150W |
| No-Load Current | 500mA |
| Internal Resistance | 90mOhm |
| Maximum Efficiency | 0.8 |
| No of Poles | 14 |
| BEC | Yes (5V/3A) |
| Max Current | 16A |
| Max Voltage | 12V |
| ESC | SimonK 30A for smooth and responsive control |
| Recommended Propeller | 10x4.5 or similar size |
| Weight | Approximately 70 grams (motor only) |
How to Use - A2212 1000KV BLDC Brushless DC Motor
- Connect the motor's 3.5mm female bullet connectors to the corresponding male connectors on the SimonK 30A ESC.
- Ensure power supply polarity is correct to avoid damage.
- Flash the ESC with SimonK firmware for optimized throttle response.
- Change the motor's direction by swapping the input supply polarity as it is bi-directional.
- Connect the ESC to your power distribution board or battery with the appropriate connectors.
- Connect the ESC signal wire to the flight controller or receiver channel designated for throttle control.
- Calibrate the ESC following SimonK firmware guidelines for optimal performance.
- Test the setup gently to ensure proper operation and correct rotation direction of the motor before proceeding with full operation.
- Adjust settings as necessary to match your specific application and requirements.
Package Includes
1 x A2212 1000KV BLDC Brushless DC Motor
1 x SimonK 30A BLDC ESC
1 x Prop Adapter
A Motor Holder (X-type) and set of screws
Additional Resources
Learn more about Brushless DC MotorExplore our drone-parts Collection
Video Tutorials
Specification
| Product Specification | Value |
| Motor KV (RPM/V) | 1000 |
| Motor Type | Brushless Motor |
| Compatible LiPO Batteries | 2S to 3S |
| Model No. | A2212 |
| Shaft Diameter (mm) | 3.17 |
| Max. Efficiency Current (A) | 4 ~ 10 |
| Max. Power (W) | 150 |
| No-Load Current (mA) | 500 |
| Internal Resistance(mOhm) | 90 |
| Maximum Efficiency | 0.8 |
| No of Poles | 14 |
| BEC (Y/N) | Yes (5V/3A) |
| Dimensions (L x W x H) mm | 45 x 24 x 9 |
| Weight (g) | 23, 64 |
| Shipping Weight | 0.067 kg |
| Shipping Dimensions | 8 × 5 × 2 cm |
