Description
Core Board STM8S103F3P6 STM8 Development Board Minimum System Board The Core Board STM8S103F3P6 STM8 Development Board Minimum System Board is engineered to provide an effective yet straightforward platform for modern embedded system designs. Benefiting from an STM8S103F3P6 microcontroller, it facilitates compact system applications by supporting Micro USB connectivity, replacing outdated USB MINI options. This board is perfect for nodemcu and fpga board enthusiasts, offering a versatile solution for development and testing new functions.
Key Features - Core Board STM8S103F3P6 STM8 Development Board Minimum System Board
- Chipboard Integration: Equipped with the STM8S103F3P6 microcontroller, offering robust performance with an 8-bit STM8 core.
- SWIM Interface: Supports debugging and programming with the SWIM debug mode.
- Micro USB Power: Uses Micro USB compatible with smartphones for easy connectivity.
- Wide Voltage Range: Input voltage from 4.5V to 15V with 3.3V output capability. Operates within 2.95V to 5.5V.
- Enhanced Storage: 640 bytes of EEPROM for expanded data handling along with 8KB of Flash Memory.
- Development Support: Compatible with STM8 programming software and hardware tools, ensuring ease for beginners.
Applications
This development board is exceptionally suited for lightweight and adaptable projects, making it a favorite in stm32 f103c8t6, esp8266 nodemcu, and esp32 board applications. It's widely adopted for educational microcontroller systems and practical in consumer electronics prototyping where cost-efficiency is prioritized. Moreover, it’s suitable for custom-designed robotics and DIY electronics endeavors.
Technical Specifications
Product Specification | Value |
Microcontroller | STM8S103F3P6 |
EEPROM | 640 bytes |
Flash Memory | 8K bytes |
RAM | 1KB |
CPU | 8-bit STM8 core |
Clock Speed | Up to 16 MHz |
Erase Cycles (Flash) | 10,000 cycles |
Operating Voltage | 2.95V to 5.5V |
Interfaces | I2C, SPI, USART |
How to Use - Core Board STM8S103F3P6 STM8 Development Board Minimum System Board
- Start by connecting the development board to a power source using a Micro USB or the 2.54 pin. Ensure the power source is within the operating voltage range of 2.95V to 5.5V.
- Use an SWIM (Single Wire Interface Module) programmer to flash your developed program onto the board.
- Utilize STM8 software tools, such as ST Visual Develop, for coding and development.
- Utilize standard communication interfaces (I2C, SPI, USART) to connect with peripheral devices or other microcontrollers.
- Integrate the board into your project enclosure, ensuring it is securely mounted and connected to other components as needed for your application.
- For detailed setup, review applicable data and circuit diagrams to familiarize yourself with pinouts and operational guidelines.
Package Includes
Core Board STM8S103F3P6 STM8 Development Board STM32 x 1
Additional Resources
Learn more about STM32Explore our development-boards Collection
Video Tutorials
Specification
Product Specification | Value |
Item Type | Development Board |
Based On | STM8 |
IC Chip | STM32F103C8T6 |
Reset Button | YES |
USB | Micro USB |
Length (mm) | 30 |
Width (mm) | 20 |
Height (mm) | 5 |
Weight (g) | 4 |
Shipping Weight | 0.005 kg |
Shipping Dimensions | 4 × 3 × 1.5 cm |
