Monster Moto Shield VNH2SP30 Motor Driver 14A (Peak 30A)

Monster Moto Shield VNH2SP30 Motor Driver is essentially a ramped-up version of our Ardumoto motor driver shield. For this Monster Moto Shield, we’ve replaced the L298 H-bridge with a pair of VNH2SP30 full-bridge motor drivers. We’ve also beefed up the support circuitry so this board is capable of driving a pair of high-current motors! Perfect for robust motor control, the Monster Moto Shield easily interfaces with compatible motor driver shields and is excellent for applications like robotics and custom electronics. The Monster Moto Shield VNH2SP30, with its high peak current management, makes it ideal for handling demanding motor shield driver tasks.

Key Features - Monster Moto Shield VNH2SP30 Motor Driver

• Voltage Max: 16V
• Maximum current rating: 30 A
• Practical Continuous Current: 14 A
• Current sensing available to Arduino analog pin
• MOSFET on-resistance: 34 mΩ (per leg)
• Maximum PWM frequency: 20 kHz
• Thermal Shutdown Protection
• Undervoltage and Overvoltage shutdown
• Compatibility with Arduino and various microcontrollers for easy integration
• Equipped with two VNH2SP30 full-bridge motor drivers with thermal protection and shutdown capability
• Capable of driving two DC motors with independent control or one stepper motor
• Support for high peak currents, allowing for exceptional torque from motors

Applications

The Monster Moto Shield VNH2SP30 offers ideal solutions for controlling motors in robotics, motor shield, and Arduino motor control l293d projects. This device effectively manages precise speed and direction changes, making it an essential component for competitive robotics and custom electronic systems. Its comprehensive protection features make it valuable in demanding applications where motor reliability is critical.

Technical Specifications

How to Use - Monster Moto Shield VNH2SP30 Motor Driver

• Ensure power supplies and connections are secure before use.
• Connect motors to output terminals, maintaining 14A limit for continuous operation.
• Use logic pin headers to connect with Arduino or compatible microcontroller for control.
• Utilize PWM pin for speed control and direction pins for H-bridge state toggling.
• Connect current sensing pins to an Arduino analog pin for monitoring motor current.
• Test connections for continuity before powering the board in high-current applications.
• Integrate thermal management strategies such as heat sinks for high-intensity usage.
• Utilize suitable software library for microcontroller programming to control motor functions.
• Start system configuration with low current and calibrate motor movements.
• Monitor current and temperature during operation to prevent overheating.

Package Includes

Monster Moto Shield VNH2SP30 Motor Driver 14A (Peak 30A) x 1

Additional Resources

Video Tutorials

Coming Soon! Check our YouTube channel for more videos.
