Description
MX1508 Motor Driver The MX1508 Motor Driver is a compact and versatile H-Bridge motor driver suitable for applications like battery-powered smart cars and robots. This motor driver is ideal for those needing an efficient solution for motor control, making it perfect for a variety of electronics projects. The L298N allows for reliable control of two DC motors or a stepper motor, offering benefits like forward/reverse motion and speed adjustment.
Key Features - MX1508 Motor Driver
- Dual H-Bridge Motor Driver, capable of controlling two DC motors or one stepper motor.
- Control over motor direction and speed using PWM (Pulse Width Modulation).
- Module supply voltage: 2V-10V.
- Signal input voltage: 1.8-7.5V.
- Single operating current: 1.5A per channel.
- Peak current up to 2.5A.
- Thermal protection with auto restore features.
- Low standby current: < 0.1uA.
- Built-in protection diodes to prevent back EMF.
- Ultra-small and compact size for ease of integration.
Applications
The MX1508 Motor Controller is excellent for robotics, automation, and DIY electronics projects that require precise motor control. With its stepper motor driver feature, it facilitates motor control in small robotics, educational purposes, and low voltage DC projects, including toy cars.
Technical Specifications
Product Specification | Value |
Module Supply Voltage | 2V-10V |
Signal Input Voltage | 1.8V-7.5V |
Single Operating Current | 1.5A per channel |
Peak Current | 2.5A |
Low Standby Current | < 0.1uA |
Mounting Hole Diameter | 2 mm |
Motor Control Method | PWM |
Built-in protection diodes | Yes, for back EMF |
How to Use - L298N Motor Driver
- Connect the module to a power source within the 2V-10V range.
- Attach the motors to the output terminals and control signals to the input pins.
- Use a microcontroller, such as an Arduino, to send PWM signals for motor control.
- Ensure secure connections to prevent malfunction and damage.
- Incorporate circuit protection to safeguard the module from overcurrent or overheating.
Package Includes
MX1508 Dual H Bridge DC PWM Stepper & DC Motor Driver x 1
Additional Resources
Learn more about L298NExplore our motor-drivers Collection
Video Tutorials
Specification
Product Specification | Value |
Module Supply Voltage | 2V-10V |
Signal Input Voltage | 1.8V-7V |
Single Operating Current | 1.5A |
Peak Current | 2.5A |
Low Standby Current | < 0.1uA |
Mounting Hole Diameter | 2 mm |
Length (mm) | 24.7 |
Breadth (mm) | 21 |
Height (mm) | 5 |
Weight (g) | 2 |
Shipping Weight | 5 |
Shipping Dimensions | 80x60x10 |
