4Ch Line Tracking Array Module - IR Sensor

IR Sensor Discover the unparalleled capabilities of the 4 IR Sensor Array Module, an advanced infrared sensor designed for precision and reliable detection. Ideal for line tracking and obstacle detection, this module elevates the accuracy and performance of robotics and automation projects. Featuring infrared detector sensors and IR detector sensors, this module provides a superior experience for all your technological applications.

Key Features - IR Sensor

• Detection range: Adjustable from 1mm to 20cm. The performance is more stable when the distance is closer. White objects reflect the infrared light the farthest.
• Size: Control panel: 42 x 38 x 12mm (L x W x H).
• Sensor: 25 x 12 x 12mm (L x W x H).
• Output interface: 6-wire interface (1234 are the signal output pins, + is the positive power pin, – is the negative power or ground pin)
• Output signal: TTL level (can be directly connected to I/0 microcontroller. When the sensor detects infrared light reflected back, the red indicator light turns on and the output is low. When there is no infrared light, the indicator light turns off and the output is high.)

Applications

Used in areas like robotics, automation, and more, where IR sensor delivers accurate results. This module acts as an infrared IR sensor and sensor IR infrared to offer comprehensive solutions.

Technical Specifications

How to Use - IR Sensor

• Integrate directly with microcontrollers taking advantage of the sensor's TTL output levels.
• Utilize the module for Arduino line tracking applications, featuring easy connectivity with its 6-wire interface.
• Deploy in projects requiring an infrared line tracking sensor to ensure precise navigation and object avoidance.

Package Includes

• 1 x 4 IR Sensor Array Module
• 12 X Male to Male Dupont Lines (20 cm long).
